Features
Simple structure: curved cover section, weather-tight seal and support bracket
Robust construction: cold-rolled steel sheet or galvanized steel sheet with surface pre-treatment, subjected to roller coating or PVC film lamination process, and then baking, curing and cooling for final formation of curved conveyor cover
Good sealing effect: curved cover section is attached to the topside of the weather-tight seal and connected to the bottom support bracket
High stability: specially treated steel sheets have stable properties, delivering long service life and corrosion protection against rain and dust
Superior look: the streamline design of the conveyor cover enables rainwater to be easily discharged while preventing the belt from moving off its original position due to strong winds
Specifications
Conveyor Belt width（mm）
Conveyor size（mm）
Full style cover（mm）
3/4 style cover（mm）
D
F
B
A
L
W
T
R1
L
W
T
R1
YDT5
500
89
125
740
800
862
846
573
423
862
846
573
423
YDT6
650
108
131
890
950
862
996
648
498
862
996
648
429
YDT8
800
108
153
1090
1150
862
1196
748
598
862
1196
748
598
YDT10
1000
133
183.5
1290
1350
862
1396
848
698
862
1396
848
698
YDT12
1200
133
183.5
1490
1570
862
1606
953
803
862
1606
953
803
YDT14
1400
159
253.5
1730
1810
862
1856
1078
928
862
1856
1078
928
YDT16
1600
159
253.5
1930
2010
862
2056
1173
1028
862
2056
1178
1028
YDT18
1800
159
283.5
2200
2280
862
2300
1280
1150
862
2300
1280
1150
YDT20
2000
159
283.5
2420
2500
862
2546
1423
1273
862
2546
1423
1273
